➤ Multiple functions for simple processed food and application for bean paste, sauce, jelly, candy, and pre-processed food, and etc..
➤ It includes gas-headed and steam-heated method benefits. It saves fuel and suitable for food heated by high temperature and long time.
➤ Belt –driven mixing system with slight noise and one speed.
➤ With enclosed motor design free from the falling bit of belt to contaminate food.
➤ Tilting by hand wheel is easy operating.
➤ All stainless steel mixing arm is simple to disassemble and easy to clean.
➤ The heat is conducted evenly and fast by the gas and insulation oil.
➤ Free from food scorched and well preserved by the consistent temperature.
➤ Mixing bowl and stove house tilted together by manual makes work efficiently.
| Model | Bowl Capacity | HP |
R.P.M. Mixing Head / Arm |
Body | Heating Method |
Bowl Dim. (m/m) |
|---|---|---|---|---|---|---|
| LB-2.4-3-D | 80L | 1HP |
60 Hz 12.7 / 26 50 Hz 10.7 / 22 |
SUS 304 |
L.P.G or Natural Gas |
720*325 |
| LB-2.8-3-D | 150L | 1.5HP | 850*430 | |||
| LB-3.0-3-D | 200L | 2HP | 920*460 | |||
| LB-3.2-3-D | 250L | 2HP | / |
* Packing size and weight might be subject to change based on different transportation.
* Due to product improvement or add on equipment, specification and weight might be changed without prior notice.
Standard Equipment :
➤ Teflon board （heat-resistant up to 250 °C）
➤ Double jacket stove house
➤ Two-layered heat transfer oil bowl
➤ Hand wheel tilting
Add on Equipment :
➤ Steel top coated with painting
➤ Inverter（variable mixing speed）
➤ Lid
➤ Wooden board (60L~150L)
➤ Stainless Steep Mixing Arm
➤ Other specifications are available
